UG

Moving Gantry type 5 Axes Machining Center

• Compact design for 5 sides & 5 axes simultaneous application jobs: Aerospace and general parts machining.
• Overhead moving gantry by twin driving system on Y axis.
• Own developed Trunion AC table provide max torque of 6000Nm on A, 2000Nm on C axis.
• Max. tool capacity of 60 is optional available.
• Heidenhain and FANUC controller both available on this field.
